The buoy uses a semi-rigid structure with four square, drag-inducing “vanes” extending from a central cylindrical hull. The center of drag is positioned at 1 meter of water depth. Positive buoyancy is obtained via 4 small floats attached to the vane arms. This design minimizes the influence of wind and the forces resulting from wave action. The DBi Iridium-CODE is the only buoy of its type that offers a single mast antenna system – further reducing wind-induced drag.
For best results and the most efficient operation, the unit should be powered up on deck to verify operation and initialize the GPS prior to deployment. If this is not possible, the buoy can simply be lowered into the water where it will self-deploy within less than 30 minutes. The packaging materials are bio-degradable so as not to damage the environment.
Optional: Extended Battey 400 days battery duration with 15 minutes reporting (standard battery will last 200 days with 15 minutes reporting)
Each SBD message will use 14 byte for Position, Water Temperature and Battery level
Included in the Package:
IRIDIUM SBD MT3300 Oceanografic Drifter Buoy
*SIE SOLLTEN einen Kostenvoranschlag zu beantragen, wenn Sie bestimmte Zubehörteile kaufen müssen, zum Beispiel eine Antenne und Kabel, so dass wir Ihnen das richtige Kabel für Ihre Antenne auf Ihrem Gerät mit allen Adaptern, die Sie benötigen.
Features:
Iridium satellite communications system
Trimble GPS
digital SST sensor
Specifications: Environmental Characteristics
- Storage Life.2 years
- Operating Temp Range..……………. -20 deg C to +40deg C
- Survival Temp Range……………....… -20 deg C - +50deg C
- Estimated Operating Life………..……….......6 mo. (varies with configuration) Electronic Systems
- Communications……..………DBi Controller/ Iridium 9602 SBD
- GPS………………………Trimble Condor C2626 or equivalent
- Temperature Sensor (optional)…………………………Digital
- Power…………….Diode-protected D-cell battery packs (30Ah) Data System
- Dataset………….……GPS location, SST, Date, Time, Voltage
- Messaging Rate………………………..per User Requirement
- Data Format…………………………...per User Requirement
- Observation Cycle……….…………..…per User Requirement Physical Characteristics
- Drag Element Cross-section .…………..…..1 meter x 1 meter
- Center-of-drag Depth…………………….…..………1 meter
- Central Tube Diameter……………...………………...90 mm
- Upper and Lower Arm Mount Diameter…….……….115 mm
- Float Diameter ………………...……….…..……..…..90 mm
- Float Tether Length…….………………….………...255 mm
